ROME · MUNICIPIO VIII · OPEN BUILDING DATA

Read the city.
Before the site visit.

Explore the scale and grain of the buildings around your next project. A starting point for architects, engineers and urban designers working in Rome.

YOUR STUDY AREA

Municipio VIII

All buildings in the supplied extract.

Context radius 250 m

Click a building to select it and show details. Click the background to set the centre. Drag to pan.

—buildings

—total footprint · m²

—median known height · m

—with height data

Inspect a building

Select a footprint to see its attributes here.

Area profile

Calculating area profile…

—building coverage

—inventory points / ha

—recorded species

—dominant species share

Area analysed: — ha

Dominant species: —

Method and limitations

Coverage uses clipped and unioned footprints. Density uses inventory points per hectare. Dominant share uses all points; species names are taken from the inventory. Circles are clipped to the municipality. Distance is straight-line from footprint to nearest inventory point, without a radius limit and within available data only: it does not measure green-space access, canopy or inventory completeness.

Colour buildings by

Building shape · method and limitations

Plan compactness = 4πA/P² (0–1): higher values indicate more compact forms. S/V ≈ P/A + 2/h (m⁻¹): lower values indicate less surface per unit of volume. Calculated in UTM 33N; perimeter includes courtyards. S/V requires a positive height and assumes a prism with all walls, roof and base exposed. Shared walls, envelope, systems and climate are not assessed. These indices do not measure energy consumption or energy rating.

Rooftop PV scenario · screening estimate

Loading PVGIS reference…

Assumed panel area / footprint 40%

—scenario yield · MWh/year

—scenario capacity · kWp

Assumes 0.20 kWp/m² of panel area, south-facing panels at 30°, free-standing mounting, and 14% system losses. The same Garbatella reference applies to every building; colours primarily reflect footprint size.

Usable area is a scenario assumption. Roof shape, setbacks, structural capacity, heritage constraints and shading from nearby buildings or trees are not assessed. PVGIS terrain horizon is included. Annual values are long-term averages, not a forecast.

Source: European Commission JRC · PVGIS 5.3 · Reference calculation & metadata

Show vegetation inventory

Loading vegetation inventory…

—inventory points

—recorded species

Most recorded species in this study area

Inspect vegetation

Hover over a coloured point for its species; click for details.

Points represent inventory records, not canopy size. Survey date and completeness are unverified; shrubs may be included. No height or crown dimensions are available.

Loading building data…

HOW TO USE THIS

A first reading of the urban fabric.

Compare small and large footprints, explore available heights, and export the buildings around a project site for further study in QGIS. Use these observations to prepare questions for your site visit.

WHAT THE NUMBERS MEAN

Radius selections include buildings whose footprint centroids fall inside the circle. Areas sum their full footprints, calculated in UTM zone 33N. They are not floor areas or roof measurements. Statistics cover the supplied extract only; circles near its edge may be incomplete.

DATA & LIMITS

Source: supplied Overture Maps building extract and Municipio VIII boundary. Grey footprints have no height value. Heights and floor counts are shown as supplied, without validation. This is context mapping, not a cadastral survey or planning assessment.

Overture attribution & licensing · Extract release date: unverified.
